VICTORY SERIES

STANDARD LED SHOE BOX

The EverLast Lighting Victory Series LED shoeboxes offers industry-leading lighting performance for multiple applications. This exterior LED fixture will continue producing light and maintaining appearance through years of extreme outdoor conditions. This fixture offers four mounting options to accommodate a variety of applications with available sensors include on/off, bi-level, and dusk-to-dawn.

  • Watts: 120w – 350w
  • Lumen Output: 15,000LM – 41,300LM
  • Color Temperature: 4000K, 5000K, 5700K, 6500K
  • EPA Rating: 0.95 ft² –1 .46 ft²
  • Input Voltage: 120-277V (AC), 347-480V (AC), 380V (DC)
  • Listings: DLC*, ETL
  • Distribution: Type V
  • Voltage: 120-277V AC, 347-480V AC
  • Mount: Flood Mount, Knuckle Slip Fitter, Round Pole, Square Pole
  • Warranty: 10-Year Warranty

*240w & 350w Only

WHERE TO BUY
SPEC SHEET

Features

The Victory Series LED shoebox is the ideal solution for your exterior area lighting needs. With several mounting and sensor options, and a Type V distribution, the Victory Series is built for performance.
  • Lumen Output:
  • 120W: 15,000 Lumens @ 5000k
  • 240W: 30,200 Lumens @ 5000k
  • 350W: 41,300 Lumens @ 5000k

(Lumen output varies based upon kelvin ratings)

  • Driver: Inventronics
  • Emitter: Luxeon
  • Rating: IP65 per ANSI C126.25-2009
  • Temperature Rating: -22° to 122°F (-30º to 50ºC)
  • Color Rendering Index: 80 CRI
  • DLC: Premium (240w & 350w only)
  • ETL: To UL 1598
  • Mechanical Materials: Extruded Aluminum Driver Housing
  • Finish: Bronze
  • Mounting Options:
    AUB:     Adjustable U-Bracket
    KSF: Knuckle Slip Fitter
Fixture
Wattage
Voltage
Color Temperature
Distribution Type
EL-LED-VS
120
240
350
UL 120-277V AC
UH 347-480V AC
40 4000K
50 5000K
57 5700K
65 6500K
V

Downloads

EverLast has resources that are built for you.

Cut Sheets

Download Cutsheet

Installation Instructions

Download Installation Instructions

IES Files

Download IES File Package

Accessories & Options

  • SENSOR
    OF ON / OFF
    BL BILEVEL
    PC     NEMA PHOTOCELL
    BLPC     BLANK PHOTOCELL

  • MOUNT
    AUB Adjustable U-Bracket
    KSF Knuckle Slip Fitter
