TITAN SERIES
STANDARD LED SHOE BOX
The Titan Series LED shoebox offers a powder coated die cast aluminum housing, dusk-to-dawn and control options, along with various mounting solutions. The Titan Series focuses on matching existing site lighting aesthetic with its traditional form factor, ease of installation, and energy reduction in an economically priced package making it ideal for quick turn-around projects.
- Limited Warranty: 10 Years
- Wattage: 150w – 300w
- Color Temperature: 3000K, 4000K, 5000K
- Lumen Output: 19,000LM – 38,000LM
- Listings: DLC,UL
- Distribution: Type III
Features
The Titan Series LED shoebox with its low profile design, and low price point is the ideal solution for your basic area lighting needs. With several mounting and sensor options, and a type 3 distribution, the Titan Series is built for your budget.
- Lumen Output:
- 150W: 18,500 Lumens @5000k
- 200W: 24,200 Lumens @5000k
- 300W: 37,600 Lumens @5000k
(Lumen output varies based upon kelvin ratings)
- Driver: Inventronics
- Emitter: Lumileds
- Rating: IP66
- Temperature Rating: -22° to 122°F (-30º to 50ºC)
- Warranty: 10-Year Limited Warranty
- Color Rendering Index: 80 CRI
- DLC: Premium
- UL: 1598
- Mechanical Materials: Extruded Aluminum Driver Housing
- Finish: Bronze
- Mounting Options:
FLMT: Flood Mount
KSFT: Knuckle Slip Fitter
SRPT: Straight Round Pole
SSPT: Surface Square Pole
Fixture
Wattage
Voltage
Color Temperature
Distribution Type
EL-LED-TS12
150
200
300
200
300
UL 120-277V AC
UH 347-480V AC
UH 347-480V AC
30 3000K
40 4000K
50 5000K
40 4000K
50 5000K
III Type III
Downloads
EverLast has resources that are built for you.
Cut Sheets
Sell Sheets
Installation Instructions
IES Files
Accessories & Options
- SENSOR
OF ON / OFF
BL BILEVEL
PC NEMA PHOTOCELL
BLPC BLANK PHOTOCELL
- MOUNT
FLMT FLOOD MOUNT
KSF KNUCKLE SLIP FITTER
SRPT SURFACE ROUND MOUNT
SSPT SURFACE SQUARE MOUNT
