COB SERIES

LED FLOOD LIGHTING

The EverLast COB Series LED flood light fixtures achieves up to 18,300 lumens. Featuring a high pressure, die-cast aluminum housing with anti-static powder coat finish, this fixture will continue producing high output LED light and looking great through years of extreme outdoor conditions. Utilizing chip on board (COB) technology, multiple LED chips are bonded directly to the substrate to form a single module. This packaging takes less space and obtains the full potential of the LED chips.

  • Limited Warranty: 10 Years
  • Wattage: 70w – 150w
  • Color Temperature: 4000K, 5000K
  • Lumen Output: 8,200LM – 18,300LM
  • Listings: DLC, ETL
REQUEST INFORMATION

Features

The EverLast Cobb Series LED flood light features a high pressure, die-cast aluminum housing with anti-static powder coat finish, this fixture will continue producing high output LED light and looking great through years of extreme outdoor conditions. Utilizing chip on board (COB) technology, multiple LED chips are bonded directly to the substrate to form a single module. This packaging takes less space and obtains the full potential of the LED chips.
  • Lumen Output:
  • 70W: 8,200 Lumens @5000k
  • 100W: 11,200 Lumens @5000k
  • 150W: 18,300 Lumens @5000k

(Lumen output varies based upon kelvin ratings)

  • Color Rendering Index: 80 CRI
  • DLC: Premium
  • ETL: To UL 1598
  • Mechanical Materials: Diecast aluminum, Anti-static powder coat finish
  • Finish: Bronze
  • Rating: IP65
  • Temperature Rating: -40° to 104°F (-40º to 40ºC)
  • Mounting Options:
  • 3/4” knuckle slipfitter (standard) or adjustable u-bracket (optional)
Fixture
Wattage
Voltage
Color Temperature
EL-LED-FLC
70
100
150
UL 120-277V AC
40 4000K 80+ CRI
50 5000K 80+ CRI

Downloads

EverLast has resources that are built for you.

Cut Sheets

Download 70w Cutsheet

Download 100w Cutsheet

Download 150w Cutsheet

Installation Instructions

Download Installation Instructions

IES Files

Download IES File Package

Accessories & Options

  • OPTIONS
    BTN1 120V BUTTON PHOTOCELL
    BTN2 208-277V BUTTON PHOTOCELL
    AUB ADJUSTABLE U-BRACKET
